Enhanced Colorimeter Color Calibration Tool for Precision Chromatic Measurement

Our traffic sign spectrophotometer features an array of built-in light sources including D65, A, C, F2, and more, coupled with a geometric light path structure of 45/0 (45 circular illumination, vertical reviewing). This instrument effortlessly measures luminance factor, chromatic coordinates, CIE Lab*, and other chromatic data of various reflective films, making it indispensable for road traffic sign testing, plastic electronics, and beyond.

Key Features:

1. Elegant Design: Seamlessly combines beautiful aesthetics with ergonomic structure design.
2. User-Friendly Interface: Boasts a 3.5-inch large capacitive touch screen for effortless navigation and operation.
3. Independent Intellectual Property: Specially developed to meet market demands, with complete independent intellectual property rights.
4. Comprehensive Measurement: Easily measures brightness factor, chromaticity coordinates, and CIE Lab* values of diverse reflective films.
5. Flexible Observer Angles: Offers two standard observer angles to cater to customer preferences for color measurement.
6. Standardized Color Modules: Built-in GB2893 safety color and GB/T18833 standard color modules for traffic sign reflection films.
7. Precise Color Index Measurement: Accurately measures multiple color indexes across various color spaces to obtain precise reflectance spectrum measurements.
8. Advanced PC Software: Equipped with feature-rich PC software for enhanced functionality.
9. High-Performance Hardware: Incorporates high hardware configuration with numerous innovative technologies.
10. Ample Data Storage: Provides large capacity storage, accommodating more than 10,000 data entries.

Experience unparalleled precision and efficiency in chromatic measurement with our cutting-edge colorimeter color calibration tool, tailored to meet the demands of diverse industries with utmost accuracy.

Specifications

Illuminating/Viewing Method:

• 45°/0° (45° ring illuminating, 0° viewing)

Features:

• Specifically designed for measuring luminance factor and color coordinates of traffic signs, markings, and reflective films, including GB 2893 and GB/T 18833 standard colors.
• Manual definition of tolerance for polygon rectangle.
• Suitable for color transmission and quality control in plastics, electronics, paint and ink, textile and garment, printing and dyeing industries.

Integrating Sphere Size:

• Φ58mm

Light Source Device:

• Combined LED Light

Sensor:

• Silicon Photoelectric Diode Array

Wavelength Range:

• 400∽700nm

Wavelength Pitch:

• 10nm

Reflectance Range:

• 0∽200%

Measuring Aperture:

• Φ8mm

Color Space:

• CIE LAB, XYZ, Yxy, LCh, CIE LUV

Color Difference Formula:

• ΔEab, ΔEuv, ΔE94, ΔEcmc(2:1), ΔEcmc(1:1), ΔE00

Other Chromaticity Data:

• WI (ASTM E313, CIE/ISO, AATCC, Hunter)
• YI (ASTM D1925, ASTM 313)
• TI (ASTM E313, CIE/ISO)
• Metamerism Index (Mt), Colour Stain, Color Fastness, Color Strength, Opacity

Observer:

• 2°/10°

Light Source Type:

• D65, D50, A, C, D55, D75, F1, F2, F3, F4, F5, F6, F7, F8, F9, F10, F11, F12

Display Data:

• Spectral Graph/Data, Sample Chromatic Value, Color Difference Value/Graph, PASS/FAIL Result, Color Offset, Color Simulation

Measuring Time:

• 1.5S

Repetitive Error:

• Spectral Reflectance: standard deviation within 0.1% (400~700nm: within 0.2%)
• Colorimetric Value: standard deviation ΔE*ab≤0.04 (Measurement Conditions: white calibration plate measured 30 times at 5 seconds intervals after white calibration performed.)

Inter-Instrument Error:

• ΔE*ab≤0.2 (Average value of measuring the 12 tint plates of BCRA series II)

Dimension:

• 9077230mm

Weight:

• 600g

Battery:

• Li-ion Battery, 5000 measurements in 8 hours

Light Source Life:

• 5 years, more than 1.6 million measurements

Display Screen:

• TFT true color 3.5 inch

Data Port:

• USB

Data Storage:

• 1000 standards, 10000 samples

Operation Temperature:

• 0∽40℃ (32∽104℉)

Storage Temperature:

• -20∽50℃ (-4∽122℉)

Standard Accessory:

• Power Adapter, Li-ion Battery, Operating Instruction, CD-ROM (containing management software), Data Line, White and Black Calibration Cavity, Protective Cover, and Wrist Strap

Optional Accessory:

• Universal Test Components, Micro Printer, Powder Test Box

• Warranty : 1 Year
• Model Number : MNSH808
• Power : Electronic
• Application : plastic, textile, wooden etc
• Usage : color/color difference test
• Accuracy : within 0.04
• Errors : within 0.2
• Weight : around 600g
• Size : 90X77X230mm
• Test speed : 1.5s
• Display : Touch Screen
