Rubber Plastic Metal Material Desktop Electronic Tensile Testing Machine Spring Tensile Strength Testing Machine

This versatile Desktop Electronic Tensile Testing Machine is designed for testing a wide range of materials including metal, non-metal (including composite materials), rubber, plastics, and adhesive materials. It enables precise testing for tensile, compression, bending, shearing, peeling, tearing, and static mechanical properties. Equipped with three closed-loop control modes—stress, strain, and displacement—it provides comprehensive test analysis.

Product Parameters:

• Capacity Selection (kg): 50, 100kg
• Unit Switching: Kgf, lbf, N, kN
• Load Resolution: 1/10,000
• Load Accuracy: ±1%
• Maximum Stroke (excluding fixture): 1000mm
• Speed Input Mode: Knob (ten turns)
• Test Speed: 30-300mm/min
• Displacement Resolution: 0.001 mm
• Data Sampling Frequency: 100Hz
• Power Supply: AC220V (can be specified by country)
• Display: Real-time value, maximum (peak), pull stop, upper and lower limit settings, point ratio setting, maximum displacement, maximum and lower limit of elongation, breakpoint ratio settings
• Motor: Stepper motor
• Rotating Rod: Ball screw or ordinary screw
• Main Engine Size: 490x380x186cm
• Machine Weight: 188lbs

This Tensile Testing Machine provides accurate and reliable results for various materials, ensuring precise measurement of tensile strength, stripping strength, bending strength, compression strength, elastic modulus, elongation at break, flexural strength, and service strength.

• Power : Electronic
• Testing speed : 30-300MM/MIN
• Electronic : AC220V/110V
• can work with : digital force gauge
• Measuring load : 500N,1000N
• Warranty : 12 Months
• Certificate : CE ISO. FCC
• Effective travel : 200-400mm (custom made 700mm)
• Operate : Manual/Auto
• Weight : 85lbs
