High-Pressure Pneumatic Water Test Pump Hydraulic Booster System

The Liquid Booster System is designed for high-pressure hydraulic testing, including proof-pressure and burst testing, with versatile applications for various industries.

Operational Instructions

1. Fill the Tank: Add water or hydraulic oil to the liquid tank and securely connect the driven air supply and the testing object, ensuring no leaks.
2. Adjust Air Pressure: Close the unloading valve, open the high-pressure liquid outlet valve, and adjust the driven air pressure to 5 bar (for example) using the air regulator.
3. Activate the System: Switch on the driven air, and the machine will begin generating high hydraulic pressure for the test.
4. End of Test: Once the test is complete, switch off the driven air, open the unloading valve to return the high-pressure liquid to the tank, and disconnect the testing object.

Structure & Composition

The liquid booster system consists of:

• Liquid booster pump
• Valves
• Gauges
• Tubes
• Mobile cart

Standard Booster System Components

1. Liquid Booster Pump: (Models: DGM, DGG, DGGD, 2DGGD)
2. F.R.L. Combination: (Function: air pressure adjustment, lubrication, impurity filtration)
3. Driven Air Switch and Pressure Gauge
4. Equipped Liquid Tank
5. High-Pressure Needle Valve
6. High-Pressure Gauge, unload valve, and pipes
7. Cabinet Options

DLS-2DGGD Series Liquid Booster System

The system offers a wide range of pressure outputs and customizable options to meet your high-pressure testing needs.

• Warranty : 13 months
• Model Number : DLSMKDG175
• Application : Automotive Industry, Industrial Utilities
• Power Source : Pneumatic
• Pressure : High Pressure
• Structure : PISTON PUMP
• Usage : Booster
• Air driven pressure : 2-8bar
• Material : 304 Stainless Steel
• Feature : High Efficiency
