Electric Heating Double Distillation
MDZ5D/MDZ10D/MDZ20D

Performance and characteristic:

• All of products are made from stainless steel.
• Have two container, and firm reasonable.
• Condenser is made of seamless stainless-steel pipes and so with very good cooling effects & great capacity of water produce.
• When lack water, will auto stop heating, when the return water reach the normal level, then continue heating.
• Composed of first distilling. second distilling water and heating two control system.
• Immerge electric heating tube made from copper, heat efficiency is better.

Specifications

Model: MDZ5D

Electric Supply: 380V/50HZ

Power: 10KW

Water discharge: ≥ 5L / h

Product size (Wooden): 67 X 43 X 86

Gross Weight : 68LBS

Net Weight : 38LBS

Model: MDZ10D

Electric Supply: 380V/50HZ

Power: 16KW

Water discharge: ≥ 10L / h

Product size (Wooden): 74 X 43 X 96

Gross Weight : 80LBS

Net Weight : 40LBS

Model: MDZ20D

Electric Supply: 380V/50HZ

Power: 32KW

Water discharge: ≥ 20L / h

Product size (Wooden): 84 X 52 X 118

Gross Weight : 120LBS

Net Weight : 77LBS
