Introducing our advanced Veterinary C-Arm equipped with state-of-the-art specifications to elevate surgical imaging:

• Generator Technology: Employs High-Frequency IGBT Inverter Combinatorial technology for precise imaging outcomes.
• Output Power: Offers a robust 3.5kW power output, ensuring efficient performance during procedures.
• KV Range: Adjustable from 40 kV to 125 kV (IEC 60613-2010), providing versatility for various veterinary applications.
• mA Range: Ranges from 0.1 mA to 50 mA, allowing for fine adjustments tailored to specific diagnostic needs.
• Focal Spot Size: Features a focal spot size of 0.6 / 1.5 mm (IEC60336), ensuring detailed and accurate imaging.
• Total Filtration: Incorporates 2.7 mm Al equivalent total filtration (IEC60522) for enhanced image quality and safety.
• Target Angle: Set at a precise 12° angle for optimal imaging results.
• Cooling Method: Utilizes oil immersed cooling technology with convection oil cooling, ensuring efficient heat dissipation during prolonged use.
• Tube Protection: Includes built-in tube protection mechanisms for added safety and longevity.
• Exposure Control: Offers continuous mode and pulse mode exposure control options with adjustable settings for optimal imaging conditions.
• C-Arm: Features a mobile C-arm design for flexibility and ease of use in various veterinary settings.
• Displayer: Equipped with a 19-inch display for clear visualization of imaging results, with an optional touch screen feature for enhanced user interaction.
• Host: Host system specifications include a CPU of ≥3GHz, internal storage of ≥8G, and a hard disk capacity of ≥1T, ensuring seamless operation and ample data storage.
• Software: Supports both Chinese and English languages, with RIS/PACS compatibility (DICOM3.0) for seamless integration with existing systems.
• Image Viewing and Processing: Offers a range of image viewing and processing features including WW/WL, zoom, movement, rotation, contrast enhancement, noise reduction, and more.
• Advanced Measurement: Provides advanced measurement tools for precise diagnostics, including Norberg Angle, TPLO, TTA, TTA2, Hip Distraction, and VHS Scaling.
• Backup and Reporting: Allows for backup images in DCM, bmp, jpg formats, and supports report editing, printing, and film typesetting.

Our Veterinary C-Arm offers unparalleled imaging capabilities, making it an indispensable tool for veterinary surgeries and diagnostics.

• maximum output power: : 3.5kw
• movement range : Vertical 400mm±8mm,Horizontal 200mm±4mm
• grid ratio : 10:1
• Focus: : 0.3/0.6mm
